Product Description
Product Description
SIZE:60x60x25mm
CONSTRUCTION:Glass Fiber reinforced plastic Impeller and housing PBT are UL 94V-0 rating
OPERATING TEMPERATURE:Ball bearing -10℃to +70℃;CycleSeal bearing -10℃ to +70℃
INSULATION RESISTANCE:10meg Ohm min, at 500 VDC(between frame and terminal)
DIELECTRIC STRENGTH:5mA max, at 500 VAC 60Hz one minute(between frame and terminal)
FUNCTION OPTIONS:FG,RD, PWM,Auto Restart, Polarity Protection
Dimensions Drawing
Dimensions Drawing
Characteristic Curves
Characteristic Curves
Specifications
Specifications
| Model | Bearing Type | Rated Voltage | Crrent | Speed | Air Flow | Static Pressure | Noise Level | Weight |
| VDC | A | RPM | CFM | mmH₂O | dBA | g | ||
| YDM6025X05F | C or B | 5 | 0.34 | 5000 | 25.47 | 5.32 | 37.70 | 60 |
| YDL6025X05F | C or B | 5 | 0.20 | 3500 | 17.61 | 2.79 | 27.50 | 60 |
| YDU6025X12F | C or B | 12 | 0.60 | 9000 | 46.76 | 17.47 | 54.00 | 60 |
| YDD6025X12F | C or B | 12 | 0.40 | 7500 | 39.17 | 12.39 | 49.83 | 60 |
| YDH6025X12F | C or B | 12 | 0.33 | 6500 | 33.45 | 9.24 | 45.80 | 60 |
| YDM6025X12F | C or B | 12 | 0.15 | 5000 | 25.47 | 5.32 | 37.70 | 60 |
| YDL6025X12F | C or B | 12 | 0.09 | 3500 | 17.61 | 2.79 | 27.50 | 60 |
| YDU6025X24F | C or B | 24 | 0.45 | 9000 | 46.76 | 17.47 | 54.00 | 60 |
| YDD6025X24F | C or B | 24 | 0.27 | 7500 | 39.17 | 12.39 | 49.83 | 60 |
| YDH6025X24F | C or B | 24 | 0.18 | 6500 | 33.45 | 9.24 | 45.80 | 60 |
| YDM6025X24F | C or B | 24 | 0.09 | 5000 | 25.47 | 5.32 | 37.70 | 60 |
| YDL6025X24F | C or B | 24 | 0.04 | 3500 | 17.61 | 2.79 | 27.50 | 60 |
| YDU6025X48F | C or B | 48 | 0.24 | 9000 | 46.76 | 17.47 | 54.00 | 60 |
| YDD6025X48F | C or B | 48 | 0.15 | 7500 | 39.17 | 12.39 | 49.83 | 60 |
| YDH6025X48F | C or B | 48 | 0.09 | 6500 | 33.45 | 9.24 | 45.80 | 60 |
| YDM6025X48F | C or B | 48 | 0.05 | 5000 | 25.47 | 5.32 | 37.70 | 60 |
| YDL6025X48F | C or B | 48 | 0.03 | 3500 | 17.61 | 2.79 | 27.50 | 60 |
1.Specifications subject to change without notiec;
2.Design and provide products according to client’s requirements.
