Product Description
Product Description
SIZE:30x30x7mm
CONSTRUCTION:Glass Fiber reinforced plastic; Impeller and housing PBT are UL 94V-0 rating Cover is stainless steel
OPERATING TEMPERATURE:CycleSeal bearing -10℃ to +70℃
INSULATION RESISTANCE:10meg Ohm min, at 500 VDC(between frame and terminal)
DIELECTRIC STRENGTH:5mA max, at 500 VAC 60Hz one minute(between frame and terminal)
FUNCTION OPTIONS:FG,RD, PWM,Auto Restart, Polarity Protection
Dimensions Drawing
Dimensions Drawing
Characteristic Curves
Characteristic Curves
Specifications
Specifications
| Model | Bearing Type | Rated Voltage | current | speed | Air Flow | static Pressure | Noise Level | Weight |
| VDC | A | RPM | CFM | mmH₂O | dBA | g | ||
| YBH3007X05 | C or B | 5 | 0.22 | 10000 | 1.38 | 9.99 | 32.71 | 9.6 |
| YBM3007X05 | C or B | 5 | 0.15 | 8000 | 1.10 | 6.39 | 26.30 | 9.6 |
| YBL3007X05 | C or B | 5 | 0.08 | 6000 | 0.80 | 3.62 | 17.83 | 9.6 |
| YBH3007X12 | C or B | 12 | 0.12 | 10000 | 1.38 | 9.99 | 32.71 | 9.6 |
| YBM3007X12 | C or B | 12 | 0.08 | 8000 | 1.10 | 6.39 | 26.30 | 9.6 |
| YBL3007X12 | C or B | 12 | 0.05 | 6000 | 0.80 | 3.62 | 17.83 | 9.6 |
1.Specifications subject to change without notiec;
2.Design and provide products according to client’s requirements.
